The 6013 electrodes offer a very steady arc as well as a smoother texture, making them frequently utilised in scenarios involving uneven or brief welding that need a shift in position. Providing a gentle, constant arc that is simple to maintain, simple slag management for lateral soldering, minimum spatter, and a lovely bead look.
The 6013 welding rod is a versatile electrode. A steel electrode that is deep penetrating and adaptable, and has consistent, smooth arc properties. To create deep penetration welding in the E6013 welding rod, the covering generates a powerful spray-type arc. It is simple to remove the thin slag.
The 6013 electrode is best used for light to medium penetration on thin or sheet metal pieces. 6013 electrodes are commonly used in manufacturing truck frame bodies, metal furniture, storage tanks, farm implementations, or where aesthetics are critical.
Standards:
- TS EN ISO 2560-A: E 38 0 RC 11
- EN ISO 2560-A: E 38 0 RC 11
- AWS A5.1: E 6013
Mechanical Properties:
- Yield Strength - (N/mm2) – Min 390
- Tensile Strength – (N/mm2) – 470 – 590
Typical Base Material Grades:
S 235JR, S275JR, S235J2G3-S355J2G3, P235 GH, P265 GH, P255NH, P235T1-P355T1,P235T2-P355T2,P235G1TH,P255G1TH,L210-L360NB,S235JRS1-S235J2S1, S235JRS2-S235J2S2
Available Sizes:
2.50 MM x 350 MM
3.20 MM x 350 MM
4.0 MM x 450 MM
